STOKA PRO

PROFORGE® Stoka Pro 5 Leg Auto Reset Tine Bar, Rear 3 Point Linkage & Depth Wheels

OVERVIEW

The New Auto-Reset Stoka Front Tine Bar is designed to couple up in front of a 3 Metre Mounted Inverta as an ideal duo combination for deep loosening of hard and compacted soil ahead of the Inverta disc system.

ALL FEATURES

  • Close couple main frame
  • Cat 3 tractor linkage
  • Frame suitable for 130-300hp tractors
  • Pin Adjust Depth Wheels for positive depth control enabling high forward speeds
  • 5 x Heavy Duty Spring Auto Reset Tines create a ground shattering action
  • Staggered tine spacing copes with high trash density
  • Tines work successfully in a depth of 50-300mm
  • Universal Double heart share point fitted as standard (very low running cost) other points options available on request
  • Can be used very successfully on its own as a deep chisel plough – ideal for busting up compacted headlands or tramlines
  • New alternative to existing Stoka bar Shear-bolt design
  • Designed to couple to a 3 Metre PROFORGE® Inverta® machine

KEY STRENGTH

5 x Heavy Duty Spring Auto Reset Tines create a ground shattering action, staggered tine spacing copes with high trash density.

ECONOMY

Can be used either paired with a 3 metre PROFORGE® Inverta® or very successfully on its own as a deep chisel plough

TESTIMONIAL

“Decent, deep, one-pass machine” – A E Atkin & Son

TECHNICAL INFORMATION

Model Weight Legs HP Required
3 Metre 700 kg 5 130-300hp (with 3 Metre Inverta)
